Color Drafting

Introduction:

In this post I go through the process of color drafting the 2-shaft weave from the previous post. For those who are new at drafting, there’s a whole chapter on drafting in my book Weaving for Beginners. Note that I begin the threading on the right and work right-to-left.

Be sure to use pencil and have a good eraser. You’ll see that I had to use it. This was my 3rd start on this, it’s easier to start over when you find mistakes.


First draw the lines defining the part of a weave draft. The chapter on drafting in my book Weaving for Beginners explains the parts of a weave draft.


Put in what you can see on the cloth—both the warps and wefts.


Assign threading to those known. I saw the weft floats first, so I assigned them to Shaft #1. Remember, I work a draft from right to left here and in my books.


Assign what colors you know: the wefts are the horizonal lines.


Add the warp colors now, the vertical lines.


Then I looked for what I could find next: verticals for warps on top on either side of yellow weft areas. NOTE: the colors are not always in the same place! Assign them a shaft: see in the tie up that shaft #2 is lifted so all the lifted warps must be on shaft #2.


Now discover what the last warp threads will be. Now I need to look below to the rows below to discover those and I see the first is orange. Again, looking for vertical threads in the cloth.


Fill in the same way for the missing spaces: see that they are all shaft 1’s and watch out to get the colors right. I see below, a warp lifted in the first rows is followed by a weft every time.


We know the weft color from the photo of the cloth so fill in the wefts (horizontals).


We see on the cloth that each warp missing is orange. See that the single warps have 1 orange and one yellow since we know the yellows (wefts) already, so the rest must be orange.


 Now we know all the warps in the threading draft AND we know some of their colors, too. So fill in the colors we know. Then we can fill in the yellow wefts but that’s easy. We still have to determine the colors of some of the warps. Again, look for rows below for the clues needed. The vertical floats are easy to see.


Now put in the treadling 1 & 2.
What’s under the grey floats, check wefts so check the image and you can see shaft 1 should be up from the treadling and see the color from the photo or further down the draft. Notice I tried to erase grey in rows 5 & 7. They should be yellow wefts colored in the treadling draft.


What goes on under all the floats you can check out first in the treadling draft: what shaft is up. Then, fill in the blanks for the wefts (horizontals). Then clean up the draft and you’re done. (I hope I haven’t made any mistakes! Let me know if you find any.)


Two-Shaft (harness) Weaving: Part One

I discovered weavers with many shafts often become interested in weaves for just two shafts. I’ve kept a file, and these fabric samples were on top. The label on the sample card says Konwiser inc. When I looked them up on the web, I found they are on the MoMa website with two furnishing fabrics dated before 1955. I don’t think they are in business now.


There are 6 colorways in the collection: all the same weave.


The third in the stack of samples. So interesting how the different colors make such a difference.


These are 52% cotton and 48% wool upholstery fabrics.


The price on the label is $14.25 and the width, 54”.


The name given to this collection is “Bahia”. My next post will be about drafting these and color drafting. In the meantime, see if you can work out the draft and if we agree.
